Milan

Item ID: 20

Turbosound Milan Series

M10 (10-inch), M12 (12-inch), M15 (15-inch) Full-Range Loudspeakers & M18B (18-inch) Subwoofer

Overview

The Turbosound Milan Series offers a versatile, professional-grade line of powered loudspeakers and subwoofers designed for exceptional portable PA and permanent installation applications. Featuring onboard Klark Teknik Class-D amplification and advanced Digital Signal Processing (DSP), these speakers deliver high-resolution sound, pristine vocal clarity, and immense power. The full-range models (M10, M12, M15) boast a lightweight, high-density composite enclosure with a dual-angle pole mount and a 2-channel mixer. The M18B bandpass subwoofer complements the tops by delivering massive, articulate bass from a rugged birch plywood cabinet. Whether used by touring musicians, mobile DJs, or in corporate A/V and house of worship setups, the Milan Series provides touring-grade performance in a user-friendly, highly scalable package.

Models & Range

• Full Range Models:
• M10: 10-inch 2-way powered loudspeaker (600W peak)
• M12: 12-inch 2-way powered loudspeaker (1100W peak)
• M15: 15-inch 2-way powered loudspeaker (1100W peak)
• Subwoofer Models:
• M18B: 18-inch powered bandpass subwoofer (2200W peak)

Key Features

• Klark Teknik DSP Technology: Advanced 24-bit DSP continuously analyzes the incoming signal to provide dynamic equalization and transparent, zero-attack limiting, ensuring optimal sound quality and driver protection at all volume levels.
• Integrated 2-Channel Mixer (Full Range Models): Each top cabinet features two independent combo XLR/TRS inputs with individual mic/line sensitivity switches, level controls, and a master 2-band EQ (Bass/Treble) alongside a selectable Speech/Music contour and a 100 Hz low-cut filter.
• Tour-Ready Construction: Full-range models are housed in heavily ribbed, injection-molded polypropylene enclosures to eliminate resonance, while the M18B subwoofer utilizes a rugged birch plywood bandpass design with steel castors for reliable low-end reproduction and easy transport.
• Versatile Placement & Rigging: The M10, M12, and M15 feature a symmetrical trapezoidal design for floor wedge monitor use, a dual-angle pole mount socket for optimized audience coverage, and multiple M10 rigging points for secure suspension.

Technical Specifications

• Amplifier Power: 600W Peak (M10), 1100W Peak (M12, M15), 2200W Peak (M18B) via Klark Teknik Class-D technology
• Low Frequency Drivers: 10-inch (M10), 12-inch (M12), 15-inch (M15), 18-inch (M18B) high-excursion woofers
• High Frequency Drivers: 1-inch high-temperature dome compression drivers mated to a converging elliptical waveguide (M10, M12, M15)
• Maximum Peak SPL: 126 dB (M10), up to 130 dB (M15)
• Frequency Response (-3 dB): 55 Hz – 18 kHz (M10), 45 Hz – 18 kHz (M15), 40 Hz – 100 Hz (M18B)
• Coverage Pattern (Full Range): 90° Horizontal x 60° Vertical
• Inputs (Full Range): 2 x balanced XLR/TRS combo jacks (Mic/Line)
• Inputs/Outputs (Subwoofer): 2 x balanced XLR inputs, 2 x XLR Thru outputs for daisy-chaining
• DSP Processing (Subwoofer): Variable bass boost filter (sweepable frequency with +6 dB gain), polarity invert switch, and overall level control
• Enclosure Materials: Injection-molded polypropylene (M10, M12, M15); Solid birch plywood with semi-matt black paint (M18B)
• Weight: 13.3 kg / 29.3 lbs (M10); 27.7 kg / 60.9 lbs (M15)

Included Accessories

• Standard IEC AC Power Cable
• Plated steel castors with rubber tires (Included with the M18B subwoofer)
• Quick Start Guide and Warranty Information
• (Note: Protective slip covers, wall mount brackets, and M10 shoulder eyebolts are sold separately)
